R32 4Motion V6-3.2L (CBRA) (2008)

Page 1
background image

Valve: Specifications

Note:

^

Valves must not be reworked. Only lapping is permitted.

Valve Dimensions for Intake Valves

Valve Dimensions for Exhaust Valves
