940 SE L4-2320cc 2.3L SOHC Turbo VIN 87 B230FT (1991)
Front Door Panel: Service and Repair
REMOVING FRONT DOOR PANEL
Remove:
-
lock knob (1).
-
plastic screws (2) behind inner door handle.
-
window handle (3).
-
screw inside window handle.
-
warning light.
-
clips inside warning light (4).
-
loudspeaker cover (5).
-1988 model; pull straight out.
1989- push cover forwards.
-
screw inside loudspeaker cover.
-
three clips (6) in boflom of trim panel.
Lift out panel at bottom. Pull straight up.
Install:
In reverse order.
