940 SE L4-2320cc 2.3L SOHC Turbo VIN 87 B230FT (1991)

Alignment: Technical Service Bulletins
Alignment - Revised Front Toe Specification
MODEL
GROUP
NUMBER
700
64
121
TITLE
ALIGNMENT SPECIFICATIONS 700/900
MARKET
DATE
US and Canada
January 1991
REFERENCE:
TP 31369/1 (ENGLISH); 03/90; FRONT SUSPENSION AND STEERING
TP 30518/9 (ENGLISH); 11/89; SPECIFICATIONS
1991 740/940/940 SE OWNER'S MANUALS
NEW FRONT ALIGNMENT SPECIFICATION - TOE - FOR ALL 700 AND 900 CARS
The Toe specification listed below for Front alignment should be used for all 700 and 900 series cars. Note that the angle tolerance has been increased
from +/- 6 min. to +/- 8 min..
PLEASE NOTE:
This Specification shall be considered to be retro-active for all 700 series as well as 900 series cars. Thus this amends the
specification stated in:
TP 31369/1; p2 and p19, Table A18.
TP 88636/8; p57
TP 30518/9; p135
Cars that have been set up to the previous specification and remain within the previous specification NEED NOT BE RE-ADJUSTED TO THE NEW
SPECIFICATION.
