C70 L5-2.4L Turbo VIN 56 B5244T (2000)
Heater Core: Procedures
Replacing the heat exchanger
Special tools:
115 8957
Before starting work on heat exchanger
NOTE!
When replacing a heat exchanger, always replace the O-rings in the pipes.
Replacing heat exchanger
Removing
Work in the engine compartment
-
Clamp the heating hoses. Use lock grip pliers 115 8957
Operations in passenger compartment
-
Remove soundproofing panels right and left-hand sides
-
Remove left and right-hand side carpet mountings.
-
Remove RTI bracket or amplifier bracket if applicable.
-
Remove knee bolster if applicable.
-
Detach drain hose and push it to one side.
-
Remove the screws on the left and right-hand side of the cover for the heat exchanger.
-
Remove the screw for the pipe flange for the heat exchanger
NOTE!
Put plenty of absorbent paper under and around the pipe flange.
