C70 L5-2.4L Turbo VIN 56 B5244T (2000)

Page 17
background image

23/446 Firewall Cable Harness

23/449 Firewall Cable Harness, CONV

23/449 Firewall Cable Harness, COUP/S70/V70

23/450 Cable Harness Soft-top

23/451 Cable Harness Soft-top
