Component Location

Component I.D. List

2/6

Overload relay 15I-supply

3/9

Stop (brake) lamp switch

7/1

Bulb failure warning sensor rear

10/17

Right tail lamp unit

10/18

Left tail lamp unit

11C/1-40 Fuses
15/4

15I-rail

24/2

Connector Firewall cable harness - Engine compartment harness

24/3

Connector Left door sill harness - Firewall cable harness

24/14

Connector Left door sill harness - Engine compartment harness

24/70

Connector Left door sill harness - Fog lamp cable harness, Power output/adapter wiring tow hitch

31/12

Ground terminal cargo compartment right-hand
