Diagram Information and Instructions|Page 5987 > < Diagram Information and Instructions|Page 5985

C70 L5-2.4L Turbo VIN 63 B5244T7 (2003)

Page 1
background image

Branching Point: Electrical Diagrams

Junction Point 23/6

Junction Point 23/8, ME7

Junction Point 23/11, Denso/ME7

Junction Point 23/203

Diagram Information and Instructions|Page 5987 > < Diagram Information and Instructions|Page 5985
