C70 Convertible L5-2.3L Turbo VIN 53 B5234T3 (1998)
Convertible Top Cable: Service and Repair
Drive Wires (Cables)
Front Lock Wires (Cables)
Before starting work, see CHA. Preparations Before Work. See: Service and Repair/Procedures
CHF1 Removal:
- Move hood to the position shown in the image.
- Ignition off.
- Make a note of any radio code.
- Disconnect the battery negative lead.
Remove:
-
compartment cover from hood for front lock motor.
-
connector.
-
2 nuts attaching front lock motor.
-
drive wire from spline joint.
- Turn motor and pull out drive wire from lock.
Remove:
-
outer fabric at forward edge of hood as described in CHG6.
-
lock cover from front cross-member.
-
cable ties holding wiring and attachment for drive wire.
-
connector from front microswitch then move it down.
