C70 Convertible L5-2.3L Turbo VIN 53 B5234T3 (1998)

Page 1
background image

Head Restraint: Service and Repair

ADA3. Rear Head Restraint

Removal
Insert your hand behind the back cushion and press the head restraint catches forward (see figure). Lift and remove the head restraint.

Installation
Press the head restraint down into the bushes and check that the catches lock.
