C70 Convertible L5-2.3L Turbo VIN 53 B5234T3 (1998)
Seat Bottom Frame: Customer Interest
Power Seat - Tilt Travel, Forward Function Inoperable
C70
1998-1999
Section
8
Group
85
No.
0017
Year
01
Month
05
Reference:
This service bulletin replaces the previous service bulletin SB 85-0017 from April 2001, which should be discarded.
Purpose:
OP time corrected. SB 85-0017 is added.
Power seat, tilt-travel-forward forward function, repair
Background:
If the travel-forward function of the front seats is not responding when tilting the backrest forward, as when entering the rear seat, the repair procedure
described in this service bulletin should be performed.
Model
Factory
Chassis No.
C70
J
Materials
Preparing the spring mounting
1
-
Move the seat as far forward as possible.
-
Raise the rear edge of the seat to the maximum position.
