C70 Convertible L5-2.3L Turbo VIN 53 B5234T3 (1998)
Fuel Gauge: Technical Service Bulletins
Fuel Gauge Sender - Replacing
Section
3
Group
38
No.
0001
Year
99
Month
02
Reference: TP 3506201, Section 3(35-38) Lighting, instrumentation and other equipment; S70/V70 1998
38-0001; Fuel gauge sender, replace; 98/10
Background:
This bulletin is a supplement to Service Manual TP 3506201, Section 3(35-38) Lighting, instrumentation and other equipment; S70/V70 1998-.
Replacement of components
Replacement of fuel gauge sender
Special tools: 999 5486
Removal of fuel gauge sender
Preparations
1
Lower the convertible top to the position shown in the illustration.
Removal of hatches and panels
2
Remove:
-
floor hatch.
