C70 Convertible L5-2.4L Turbo VIN 56 B5244T (2000)
Roll Bar Control Module: Service Precautions
ABA. Control modules
Connecting and disconnecting control modules
The ignition must always be switched off when connecting and disconnecting the control modules, connectors and breakout box.
The ignition should also be switched off when measuring with the ohmmeter.
Temperature
The control modules must not be heated above 80 °C. Remove the control modules when for example baking paint.
Arc welding
Always remove the battery negative lead, to prevent closed circuits occurring.
Position the welding ground as close to the welding site as possible, otherwise different ground potentials could be generated in different components.
If welding is to take place in the immediate vicinity of a control module, the control module must be removed to avoid heat damage.
Replacing
Do not replace a control module without checking its wiring and components. The new component may be damaged in the same way as the old one.
ABB. Radio
NOTE! Make a note of the radio code before disconnecting the battery leads and the car is without voltage supply Re-enter the code when the work has
been completed.
