C70 Convertible L5-2.4L Turbo VIN 56 B5244T (2000)
Convertible Top Cable: Service and Repair
Drive Wires (Cables)
Rear Latch Arm Drive Wire (Cable)
REMOVING THE DRIVE WIRE FOR THE REAR LATCH ARM
Remove the 12 screws from the bracket for the motors.
Fold the motor bracket forward.
Note: The bracket for the motors may be secured with butyl tape.
Heat up the metal with a hot air gun.
Remove:
-
the locking for the wires
-
the drive wire from the motor.
Remove the drive wire from the rear latch arm (spline joint).
Draw the wire out through the hole in the motor bracket.
Replace the wire.
