C70 Convertible L5-2.4L Turbo VIN 56 B5244T (2000)
Traction Control Module: Testing and Inspection
Signal specification, ABS/DSTC (dynamic stability and traction control) control module
All the values given are between the relevant terminal in column 1 and terminals #A15 or #A46 (ground), unless otherwise indicated in brackets.
Note!
It is important that the breakout box is connected and that the ground terminals have been checked before readings are taken.
