C70 Convertible L5-2.4L Turbo VIN 56 B5244T (2000)
Hose/Line HVAC: Procedures
Replacement Refrigerant Pipe/Hose or Expansion Valve
Special tools: 999 5385, 999 5472
TTTM1 Before starting work on refrigerant circuits
WARNING! FOLLOW THE SAFETY PRECAUTIONS FOR WORK ON NC SYSTEMS ACCORDING TO AC. SAFETY INSTRUCTIONS
WHEN HANDLING REFRIGERANT See: Heating and Air Conditioning/Service Precautions/Technician Safety Information
NOTE! At the Receiver/Drier always install new O rings in pipes and quick-release connectors. Always plug pipes and couplings when working on the
climate control system system.
NOTE! Read the section on oil in the system according to BG. See: Heating and Air Conditioning/Service and Repair
Replacing refrigerant pipe/hose; compressor - condenser
TTTM2 Removing refrigerant pipe/hose; compressor - condenser
-
First read TTTM1.
-
Drain system of refrigerant according to BD. (See above)
-
Raise car.
-
Remove air baffle.
-
Detach pipe/hose from condenser.
-
Detach pipe/hose from compressor.
TTTM3 Installation of refrigerant pipe/hose; compressor condenser
In reverse order.
Tightening torque 25 ±6 Nm (19 ±4 ft.lb).
Replacing refrigerant pipe/hose; condenser - member
