Cruise Control Switch: Procedures

Selector Switch, Replacement

Ignition off.
Tilt steering wheel to lower position.
Remove six screws holding steering column covers.
Remove locking screw that holds steering wheel adjustment lever, using a 3 mm hex wrench.
Remove upper and lower steering column covers.
Disconnect selector switch connector.
Remove the two screws holding the selector switch.
Install new selector switch.
Reinstall in reverse order.
Test operation.
