S70 AWD L5-2.4L Turbo VIN 56 B5254T (1999)
![background image](/volvo/s70_awd/l5-2.4l_turbo_vin_56_b5254t/Page-1278001.png)
Wheel Speed Sensor: Service and Repair
Front Wheel Sensor, Replacement
Front wheel sensor, replacement
Special tools: 115 8147
Preparations
^
Ignition off.
^
Remove wheel.
Removing sensor
Note: Clean sensor and connector carefully before removing them.
^
Remove sensor mounting bolt and pull sensor out.
^
Remove connector.
Installing sensor
^
Clean sensor seat free of dust and rust so sensor ends up in right position relative to pulse wheel.
^
Brush any dirt off of pulse wheel. Use a soft brush.
^
Install sensor and tighten bolt to 10 Nm (7.5 ft. lbs.).
^
Install connector.
Installing wheel
