S70 GLT L5-2.4L Turbo VIN 56 B5254T (1998)
![background image](/volvo/s70_glt/l5-2.4l_turbo_vin_56_b5254t/Page-1895002.png)
-
Fold down right rear seat backrest.
-
Remove the rear hatch and both side panels.
-
Fold up the front hatch, unscrew the two screws on each side, pull the hatch backward and lift up.
-
Fold back cargo compartment carpet to the left.
DDL5 Disconnecting Connector:
-
Disconnect fuel level sensor connector, SB, and separate wiring.
DDL6 Removing Covers:
-
Remove plastic cover over fuel level sensor cover. Put to one side.
-
Remove covers over fuel level sensor and fuel pump (FP).
DDL7 Removing Fuel Level Sensor:
