V70R AWD L5-2.3L Turbo VIN 52 B5234T6 (1998)

Sensors and Switches > Sensors and Switches - Instrument Panel > Fuel Gauge Sender > Component Information > Technical Service Bulletins > Page 811

Page 2
background image

-

When work on the level sensor is finished tighten the fuel tank straps.

-

Raise the car.

-

Press the fuel tank forwards so that the level sensor nut is centered in the hole in the panel.

-

Tighten the fuel tank.

-

Lower the car.

-

Reinstall. See: Service and Repair

Sensors and Switches > Sensors and Switches - Instrument Panel > Fuel Gauge Sender > Component Information > Technical Service Bulletins > Page 811
