Intake Air Temperature Sensor: Description and Operation (page 2 of 2)

Make

Volvo

Model

XC70

Engine

L5-2.5L Turbo VIN 59 B5254T2

Year

2003

Section

Computers and Control Systems › Sensors and Switches - Computers and Control Systems › Intake Air Temperature Sensor

Powertrain ManagementDescription and Operation · page 2 of 2

Intake Air Temperature Sensor: Service and Repair

Temperature And Pressure Sensors, Replacing

Removal and installation

NOTE:  As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the
essential information in the illustrations is always correct.

Removing the temperature and pressure sensors

Remove the boost pressure sensor which is on the pipe coming from the charge air cooler (CAC).

Installing the temperature and pressure sensors
Install a new sensor.
