Page 83
background image

11F Fuses In Cargo Compartment Auxiliary Fuse Box

11M Fuses in spare fuse holder, cargo compartment XC90 (2006 Late Version)

15/31 Distribution Box In Engine Compartment

16/1 Audio Module (AUM)

Relays and Modules > Relays and Modules - Powertrain Management > Relays and Modules - Emission Control Systems > Air Injection Pump Relay > Component Information > Diagrams > Diagram Information and Instructions > Page 1890
