XC90 AWD V8-4.4L VIN 85 B8444S (2005)

Relays and Modules > Relays and Modules - Transmission and Drivetrain > Relays and Modules - Differential > Control Unit, Differential Lock > Component Information > Diagrams > Diagram Information and Instructions > Page 2511

Page 1
background image

Control Unit: Electrical Diagrams

Differential Electronic Module (DEM)

Differential Electronic Module (DEM)

Diagram Legend:  See: Diagrams/Diagram Information and Instructions/Diagram Legend

Wire Color Code Identification and Other Abbreviations:  See: Diagrams/Diagram Information and Instructions/Wire Color Code Identification and
Other Abbreviations
