Oil Pressure Sensor: Service and Repair
Oil pressure sensor, replacing
Note! The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the
Removing protective plate
Remove the 6 screws.
Note! There is a guide sleeve on the upper mounting for the plate. This must be lifted slightly so that the panel can be slid forward.
Lift and slide the protective plate forward. Remove the protective plate.
Removing the splash guard under the engine
