Diagram Information and Instructions|Page 14730 > < Diagram Information and Instructions|Page 14728

XC90 FWD L6-3.2L VIN 98 B6324S (2007)

Page 1
background image

Auxiliary Power Outlet: Electrical Diagrams

12V Outlet

12V Outlet

Diagram Legend:  See: Diagrams/Diagram Information and Instructions/Diagram Legend

Diagram Information and Instructions|Page 14730 > < Diagram Information and Instructions|Page 14728
