A4 Mk3

Removing and installing selector lever sensors control unitJ587
Removing and installing selector lever sensors control unit -J587-

Removing
–  Remove selector lever handle → Chapter.
–  Remove multimedia system operating unit -E380- → Communication; Rep. gr.91.
–  Remove front ashtray → General body repairs, interior; Rep. gr.68.
  A68-10296
–  Unplug electrical connector -1-.
–  Release 4 retaining tabs -arrows- and lift out selector lever sensors control unit -J587-.
  Note
-Arrows A- can be disregarded.
Installing
Installation is carried out in reverse sequence; note the following:
–  Make sure selector lever sensors control unit -J587- clicks in place with 4 retaining tabs -arrows-.
–  Secure wiring for selector lever position display -Y26--arrows-.
–  Install front ashtray → General body repairs, interior; Rep. gr.68.
–  Install multimedia system operating unit -E380- → Communication; Rep. gr.91.
–  Install selector lever handle → Chapter.
  A37-10416
