300Tdi Engine Timing Belt Tensioner and Gears Removal
ENGINE
OVERHAUL
5
6. Remove 3 bolts securing fuel injection pump
gear and hub plate to pump hub.
CAUTION: Do not remove nut securing
hub to fuel injection pump.
7. Remove timing pin LRT-12-045.
8. Remove fuel injection pump gear and hub
plate.
Inspecting components
1. Check timing gear teeth for burrs.
2. Remove all traces of gasket from timing belt
front and rear covers using suitable gasket
removal spray and a plastic scraper.
