Discovery II
SEATS
76-5-18 REPAIRS
Seat - rear
$% 78.10.48.99
This procedure is applicable to both rear seats.
Remove
1. Carefully pull carpet away from the rear seat
base to gain access to mounting brackets.
2. Remove 2 Torx bolts securing front of mounting
brackets to floor.
3. Fold rear seats fully forward.
4. Remove the 2 Torx bolts securing rear of
mounting brackets to floor.
5. Remove rear seat.
Refit
1. Position rear seat to floor in the fully folded
position. Fit Torx screws to rear of mounting
brackets and tighten to 45 Nm (33 lbf.ft).
2. Position rear seat in upright position. Fit Torx
bolts to front of mounting brackets and tighten
to 45 Nm (33 lbf.ft).
3. Position front carpet.
