Freelander Service Procedures
IN CAR ENTERTAINMENT
REPAIRS
86-6-9
Speaker - tweeter - rear - 3 door
$% 86.50.35
The procedure to remove the tweeter on 5 door
models is the same as shown for a 3 door, except
that the rear door trim casing has to be removed and
not the body side rear trim casing.
Remove
1. Remove body side rear trim casing.
REPAIRS, Trim casing - body side - rear - 3
door.
2. Remove ring securing tweeter and remove
tweeter
Refit
1. Fit tweeter, ensuring lug on tweeter is aligned
with cut-out in trim casing, fit and tighten
securing ring.
2. Fit body side rear trim casing.
