Freelander Service Procedures
IN CAR ENTERTAINMENT
86-6-10 REPAIRS
Amplifier - power
$% 86.50.36
Remove
1. Slide LH front seat fully rearwards.
2. Remove 2 bolts securing power amplifier cradle
to bracket.
3. Withdraw power amplifier and cradle assembly,
disconnect multiplug from power amplifier and
remove assembly.
4. Remove 3 bolts securing power amplifier to
cradle and remove power amplifier.
Refit
1. Locate power amplifier to cradle and fit and
tighten bolts.
2. Connect multiplug and locate power amplifier
and cradle assembly to bracket.
3. Fit and tighten bolts securing cradle to bracket.
4. Position seat to mid position.
