Freelander Service Procedures
RESTRAINT SYSTEMS
75-6
REPAIRS
Stalk - rear seat belt - LH - 3 door
$% 76.73.32
Remove
1. Remove rear seat.
SEATS, REPAIRS, Cushion & squab
- rear seat - bench type - 3 door.
2. Remove 2 screws from hinge cover and
remove cover from seat hinge.
3. Remove 4 screws and remove rear seat centre
console.
4. Release rear seat cushion cover retainers and
position cushion aside.
5. Remove Torx bolt from seat belt buckle and
remove buckle.
Refit
1. Fit buckle to seat frame and tighten Torx bolt to
32 Nm (24 lbf.ft).
2. Position seat cushion and secure cover
retainers.
3. Fit centre console and secure with screws.
4. Fit hinge cover and secure with screws.
5. Fit rear seat.
