Range Rover P38
17
EMISSION CONTROL
NEW RANGE ROVER
10
REPAIR
SOLENOID - EVAP CANNISTER VENT VALVE
(CVS)
Service repair no - 17.15.47
Remove
1. Disconnect multiplug from CVS unit.
2. Remove clip securing hose to CVS unit.
3. Disconnect hose from CVS unit.
CAUTION: Plug the connections.
4. Remove CVS unit from bracket.
Refit
5. Fit CVS unit to bracket.
6. Connect hose to CVS unit.
7. Fit clip to secure hose to CVS unit.
8. Connect multiplug to CVS unit.
CONTROL VALVE - SECONDARY AIR INJECTION
(SAI)
Service repair no - 17.25.02
Remove
1. Release clip and disconnect air hose from valve.
2. Disconnect vacuum hose from valve.
3. Remove 2 bolts securing valve to air manifold.
4. Remove valve and discard gasket.
Refit
5. Clean air valve and mating face on manifold.
6. Fit new gasket and fit valve. Tighten bolts to
10
Nm (7 lbf.ft) .
7. Connect vacuum hose.
8. Connect air hose and secure with clip.
