Range Rover Classic
86
ELECTRICAL
24
REPAIR
EXTERIOR DRIVING MIRRORS MOTOR
Remove
1. Disconnect battery negative lead.
2. Remove mirror glass.
See CHASSIS AND
BODY, Repair, Exterior Driving mirror
3. Remove 4 screws securing motor.
4. Position motor to obtain access to electrical
connections.
5. Disconnect harness from motor, remove motor.
Refit
6. Position motor, connect harness.
7. Fit and tighten securing screws.
8. Fit mirror glass.
See CHASSIS AND BODY,
Repair, Exterior driving mirroe
9. Reconnect battery negative lead.
CONTROL SWITCHES
Service repair no - 86.65.75 - Switches
Service repair no - 86.45.29 - Bulbs
NOTE: The following operation covers the
exterior driving mirror, rear screen wash,
rear screen wipe and petrol filler flap
switches and bulbs.
Switch replacement
Remove
1. Disconnect battery negative lead.
2. Release turnbuckles, lower driver’s access
panel.
3. Depress lugs retaining appropriate switch, press
switch from panel.
4. Disconnect multiplug from switch, remove
switch.
Bulb replacement
5. Identify bulb to be replaced and remove
appropriate switch.
6. Rotate bulb holder 90 deg. and withdraw it from
switch; discard bulb holder and bulb.
Refit
7. Reverse removal procedure.
