Range Rover Classic
ELECTRICAL
23
REPAIR
OIL PRESSURE WARNING SWITCH - V8i
Service repair no - 86.65.30
Remove
1. Disconnect battery negative lead.
2. Disconnect electrical lead.
3. Unscrew switch unit.
4. Remove switch and sealing washer.
Refit
5. Reverse removal procedure. Using a NEW
sealing washer.
PARK BRAKE WARNING SWITCH
Service repair no - 86.65.45
Remove
1. Remove centre console.
See CHASSIS AND
BODY, Repair, Centre Console
2. Apply park brake.
3. Reposition hose at side of bracket to gain
access to switch.
4. Remove screw securing switch.
5. Withdraw switch, disconnect Lucar, remove
switch.
Refit
6. Reverse removal procedure.
