Range Rover Classic
86
ELECTRICAL
22
REPAIR
REVERSE LIGHT SWITCH
Service repair no - 37.27.01
Manual gearbox
Remove
Reverse light switch is located at rear of selector
housing, accessible from beneath vehicle.
1. Place vehicle on suitable ramp.
2. Disconnect battery negative lead.
3. Disconnect electrical leads.
4. Release lock-nut.
5. Remove switch.
Refit
NOTE: Reverse light switch requires
re-setting on reassembly.
6. Select reverse gear.
7. Connect 12 volt supply and test lamp across
switch terminals.
8. Screw switch into housing until test lamp is
illuminated. Screw switch in a further half turn,
tighten locknut.
9. Connect electrical leads.
10. Reconnect battery negative lead.
START INHIBIT / REVERSE LIGHT SWITCH
Service repair no - 44.15.19
Automatic gearbox
Remove
Reverse light switch is an integral part of start inhibitor
switch. It is located on left hand side of gearbox,
accessible from beneath vehicle.
1. Place vehicle on suitable ramp.
2. Disconnect battery negative lead.
3. Disconnect multi-plug.
4. Release clamp bolt, remove clamp.
5. Remove switch.
Refit
6. Fit a new ’O’ ring to switch.
7. Reverse removal procedure.
