Range Rover Classic
86
ELECTRICAL
20
REPAIR
IGNITION/STARTER SWITCH
Service repair no - 86.65.02
Remove
1. Remove steering column lock.
See STEERING,
Repair, Steering Column Lock Assembly
2. Remove screw securing ignition/starter switch,
remove switch from lock barrel.
Refit
3. Position switch to lock barrel ensuring peg is
inserted in switch, fit and tighten screw.
4. Fit steering column lock.
See STEERING,
Repair, Steering Column Lock Assembly
REAR TAILGATE SWITCH
Service repair no - 86.65.22
Remove
1. Disconnect battery negative lead.
2. Remove single screw securing switch to tailgate
opening.
3. Withdraw switch.
4. Disconnect electrical lead.
Refit
5. Reverse removal procedure.
