Range Rover Classic
ELECTRICAL
51
REPAIR
SPEEDOMETER
Service repair no - 88.30.01
Remove
1. Remove instrument cowl.
See Instrument
Cowl and Illumination Board
2. Remove speedometer trip reset button sleeve.
3. Remove instrument face plate.
4. Remove 4 screws securing speedometer,
remove speedometer.
Refit
5. Reverse removal procedure.
TACHOMETER
Service repair no - 88.30.21
Remove
1. Remove circuit board.
See Circuit Board
2. Remove instrument cowl.
See Instrument
Cowl and Illumination Board
3. Remove speedometer trip reset button sleeve.
4. Remove instrument face plate.
5. Remove 3 screws securing tachometer to
binnacle, remove tachometer.
Refit
6. Reverse removal procedure.
