Range Rover Classic
ELECTRICAL
37
REPAIR
ALARM HORN
Service repair no - 86.77.10
Remove
1. Remove decker panel.
See CHASSIS AND
BODY, Repair, Decker Panel
2. Disconnect two Lucar connectors.
3. Remove single nut securing horn.
4. Remove horn.
Refit
5. Reverse removal procedure.
GEAR SELECTOR-INTERLOCK
Interlock solenoid
Remove
1. Disconnect battery negative lead.
2. Remove gear selector head and illumination
panel.
See CHASSIS AND BODY, Repair,
Centre Console
3. Disconnect electrical multiplug.
4. Remove screws and lift gear selector
mechanism above housing.
5. Remove screws from microswitch support
bracket.
6. Remove screws and separate side cover from
housing.
7. Disconnect wiring solenoid to multiplug.
8. Remove circlip and retainer plate.
9. Remove clip and centre sleeve.
10. Refit clip into groove on spindle and lever
against it to remove solenoid from housing.
