76
CHASSIS AND BODY
12
REPAIR
BONNET
Service repair no - 76.16.01
Remove
1. Disconnect battery negative lead.
2. Disconnect electrical leads to under
bonnet[hood] lamp and heated washer jets.
3. Disconnect windscreen washer tube at ’T’ joint.
4. With assistance release four bolts securing
bonnet[hood] to hinges. Note ground strap
located onto left hinge for reassembly. Lift
bonnet[hood] clear of vehicle.
Refit
5. Fit bonnet[hood] ensure ground strap is refitted.
Before final tightening of bolts align bonnet[hood]
with decker[cowl] panel, wing[fender] and front
grille.
6. Reverse removal procedure.
DECKER PANEL
Service repair no - 76.10.35
Remove
1. Disconnect battery negative lead.
2. Remove bonnet[hood].
See Bonnet
3. Remove wiper arms and two nuts securing
wheel boxes to decker[cowl] panel. Remove two
exterior sealing rubbers.
4. Remove nine screws securing front of
decker[cowl] panel.
