Range Rover Classic
CHASSIS AND BODY
35
REPAIR
ASYMMETRIC SPLIT REAR SEAT
Service repair no - 76.70.38
Remove
1. Lift footwell carpet to access front hinge bolts.
2. Remove hinge bolts.
3. Fold seat fully forward.
4. Remove rear hinge bolts.
5. Remove seat from vehicle.
Refit
6. Reverse removal procedure. Ensure seat folds
and latches smoothly.
ASYMMETRIC SPLIT REAR SEAT - LOCKING
MECHANISM
Service repair no - 76.70.51
Remove
1. Depress release button and fold seat forward.
2. Unscrew and remove release button.
3. Remove two trim buttons securing trim cover.
4. Remove trim cover.
5. Remove three screws securing latch to tower.
One screw is accessed through hole in tower.
6. Retrieve latch from opening rear of tower.
7. Remove operating rod by releasing plastic clip.
