Range Rover Classic
CHASSIS AND BODY
41
REPAIR
11. Open glovebox lid.
12. Remove 5 screws securing console.
13. Release 2 clips, securing front of console to
bracket.
14. Release handbrake gaiter from console.
15. Remove spring clip (from RH side) and clevis pin
securing cable to handbrake lever.
16. Lift handbrake lever and manoeuvre console
slightly away from tunnel.
17. Disconnect Lucar connectors from cigar lighter.
18. Lift console assembly over handbrake and gear
levers and remove from vehicle.
Refit
19. Reverse removal procedure. Ensure electrical
plugs are fitted correctly and wiring is not
trapped.
20. Lubricate handbrake clevis pin.
DRINKS TRAY
Service repair no - 76.46.41
Remove
1. Disconnect battery negative lead.
2. Remove ash tray.
3. Release air suspension switch panel from dash
and position below aperture.
See
ELECTRICAL, Repair, Air Suspension
Switches and Bulbs
4. Remove 6 screws securing drinks tray to dash.
5. Remove drinks tray assembly.
Refit
6. Reverse removal procedure.
