Range Rover Classic
76
CHASSIS AND BODY
38
REPAIR
SEAT BELTS
Introduction
Seat belt assemblies are factory fitted. If removal is
necessary follow procedures in this section. All seat
belt fixings MUST be tightened to correct torque
values.
Seat belt assemblies MUST be replaced after they
have been subjected to loading such as in a collision.
A lamp warning is incorporated to alert user. The
warning lamp will illuminate for eight seconds when
ignition is switched on regardless of seat belt usage.
On American specification vehicles a audible warning
will sound with an high and low note from four to eight
seconds unless driver seat belt is fitted.
A lap belt is provided for occupant of the centre rear
seat.
FRONT SEAT BELT
Service repair no - 76.73.10
Remove
1. Move seat to access belt mountings.
2. Disconnect battery negative lead.
3. Remove seat side trim panel.
See Front seat
4. Remove bolt, plain washer and spacer from belt
to seat base.
5. Remove moulding from adjustable seat belt
mounting.
6. Remove nut and spacer securing seat belt to
’B’post.
