Range Rover Classic
CHASSIS AND BODY
53
REPAIR
GLASS SUNROOF
Operation
The sunroof operates in a tilt and slide action
controlled by a rocker switch near the interior lamp.
A drive motor and control unit is located behind the
switch and interior lamp panel. The control units
function is to stop the drive motor at the full tilt and
slide positions.
Removal and refit of sunroof assemblies shown can
be carried out without removing complete sunroof
assembly.
GLASS PANEL ASSEMBLY
Service repair no - 76.82.64
Remove
1. Open sunroof to tilt position.
Refit and Adjust
1. Remove mechanism covers. Slide rearwards to
disengage from location and lift out.
2. Remove two screws from each side as shown.
3. Remove glass sunroof.
4. Fit glass sunroof.
5. Fit four screws but do not tighten.
6. Close sunroof.
7. Check height of sunroof panel against roof
aperture. The trimmed edge of glass sunroof to
stand 1mm above roof aperture.
8. Adjust by moving sunroof panel up or down.
Tighten screws.
9. Fit mechanism covers.
10. Check sunroof operates correctly.
