Range Rover Classic
76
CHASSIS AND BODY
40
REPAIR
5. Remove bolt and plain washer securing belt
bracket to load space floor.
6. Centre lap strap only: Remove bolts securing lap
strap and buckle assembly and withdraw both
components.
Refit
7. Reverse removal procedure. Ensure belts are
not twisted. Tighten bolts to
25Nm.
CENTRE CONSOLE
Service repair no - 76.52.00
Service repair no - 76.25.09 Veneer panel
Service repair no - 76.25.25 Switch panel
Remove
1. Disconnect battery negative lead.
2. Remove cigar lighter.
3. Release gaiter and unscrew transfer gear lever
knob.
4. Lift at front and remove finisher from automatic
gear selector housing.
5. Lift at front and remove veneer panel.
6. Remove switch panel veneer.
7. Remove 4 screws securing switch panel.
8. Withdraw switch panel from console.
9. Disconnect multiplugs from 9 switches.
10. Remove switch panel assembly.
