WINDSCREEN WASHER TUBES

WIPERS AND WASHERS

3

REPAIR

HEATED WINDSCREEN WASHER JETS
THERMOSTAT

Service repair no - 84.10.12.

The thermostat is located on right headlamp mounting
panel.

Remove

1. Disconnect battery negative lead.
2. Remove radiator grill.

See CHASSIS AND

BODY, Repair, Radiator Grille

3. Remove two screws securing thermostat to right

hand headlamp mounting panel.

4. Withdraw thermostat, disconnecting electrical

connector.

Refit

5. Reverse removal procedure.

WINDSCREEN WASHER TUBES

Service repair no - 84.10.15.

Remove

1. Disconnect tubing from reservoir pump.
2. Disconnect tubing from washer jets.
3. Disconnect tubing from three-way tee piece.
4. Release tubing from edge clips.

Refit

5. Reverse removal procedure.
