Range Rover Classic
ELECTRICAL
33
REPAIR
MEMORY SEAT - SWITCH
Service repair no - 86.75.03
Remove
1. Disconnect battery negative lead.
2. Pry finger tip controls from top of switch housing.
3. Remove switch housing cover by lightly
depressing sides of switch housing to disengage
clips.
4. Remove sealing membrane.
5. Remove switch securing screws, lift switch to
gain access to multiplugs.
6. Disconnect multiplugs and remove switch.
Refit
7. Reverse removal procedure. Renew sealing
membrane.
MEMORY SEAT SWITCH - CLEAN
NOTE: If a seat switch problem is
diagnosed, the cause may be liquid
spillage or ingress of foreign matter. The
switch may be cleaned using the following
procedure.
1. Remove seat switch.
See Memory Seat -
Switch
2. Discard sealing membrane.
3. Clean affected area of switch using a slightly
damp clean cloth.
4. If contamination still exists, clean switch using a
clean cloth slightly dampened with methylated
spirits.
5. Allow switch to dry completely.
6. Refit switch using a new membrane.
7. Check seat switch for satisfactory operation.
