Range Rover Classic
86
ELECTRICAL
10
REPAIR
DIRECTION INDICATOR/SIDE REPEATER LAMP
BULB REPLACEMENT
Service repair no - 86.40.65
Remove
1. Disconnect battery negative lead.
2. Release clips securing wheel arch liner.
3. At back of lamp, twist bulb holder anti-clockwise
to remove from lamp assembly.
4. Remove bulb.
Refit
5. Reverse removal procedure.
TAIL LAMP ASSEMBLY
Service repair no - 86.40.74
Remove
1. Disconnect battery negative lead.
2. Remove four lens retaining screws.
3. Remove lens.
4. Remove sealing rubber, if required.
NOTE: To remove sealing rubber complete
it is necessary to remove side marker lens.
5. Remove bulbs.
6. Remove four screws securing lamp unit to body.
7. Remove two through-screws from reflector side,
which also secure lamp unit to body.
8. Ease lamp unit forward and disconnect leads at
moulded connectors.
Refit
9. Reverse removal procedure.
