Range Rover Classic
86
ELECTRICAL
18
REPAIR
HEADLAMP/FLASHER SWITCH AND
WINDSCREEN WASH/WIPE SWITCH
Service repair no - 84.15.34 - Wash wipe switch
Service repair no - 86.65.41 - Headlamp/flasher
switch
NOTE: The following procedure applies to
either switch.
Remove
1. Remove steering column shroud.
See
STEERING, Repair, Steering Column Shroud
2. Position steering wheel for access.
3. Remove 2 screws securing switch.
4. Insert a suitable, flat bladed tool between switch
and casing, depress raised ’pip’, release switch
from casing.
5. Disconnect switch multiplugs.
Refit
6. Connect switch multiplugs.
7. Position switch to casing ensuring ’pip’ is
engaged.
8. Reverse removal procedure. 1 and 3.
HAZARD WARNING SWITCH AND BULB
Service repair no - 86.65.50 - Switch
Service repair no - 86.45.29 - Bulb
Switch replacement
Remove
1. Disconnect battery negative lead.
2. Remove ashtray.
3. Carefully release panel from fascia.
4. Disconnect multiplug from switch.
5. Depress retaining lugs, remove switch from
panel.
Bulb replacement
6. Rotate bulb holder 90 deg. and withdraw it from
switch, discard bulb holder and bulb.
Refit
7. Reverse removal procedure.
