ELECTRICAL
15
REPAIR
INTERIOR ROOF LAMP
Service repair no - 86.45.01
Remove
Interior roof lamps are operated automatically via side
door and tailgate courtesy switches or by an
independent switch in auxiliary switch panel.
1. Disconnect battery negative lead.
2. Remove lens from courtesy lamp by pressing
upward and turning it counter-clockwise.
3. Withdraw bulb from spring clip holder.
4. Remove screws securing lamp base to roof
panel.
5. Lower lamp to reveal cable snap connections.
6. Disconnect electrical connections.
Refit
7. Reverse removal procedure.
STARTER MOTOR - V8i ENGINE
Service repair no - 86.60.01
Remove
1. Place vehicle on a suitable ramp [hoist].
2. Disconnect battery negative lead.
3. Disconnect leads from solenoid and starter
motor. Remove exhaust heat shield.
4. Remove two bolts, starter motor to flywheel
housing.
5. Remove starter motor.
Refit
6. Reverse removal procedure.
