Range Rover Classic
ELECTRICAL
17
REPAIR
AIR SUSPENSION SWITCHES AND BULBS
Service repair no - 86.65.88 - Switches
Service repair no - 86.45.29 - Bulbs
Switch replacement
Remove
1. Disconnect battery negative lead.
2. Carefully release lower edge of panel from
surround, withdraw panel.
3. Noting their fitted positions, disconnect
multiplugs from switches.
4. Depress retaining lugs on switches, remove
switches from panel.
Bulb replacement
5. Identify bulb to be replaced and remove
appropriate switch.
6. Rotate bulb holder 90 deg. and withdraw it from
switch.
Refit
7. Reverse removal procedure.
