V8 Engine 3.5 3.9 4.2
ENGINE
44
OVERHAUL
Flywheel - refit
1. Ensure bolt holes in crankshaft are clean and
dry.
2. Fit flywheel and locate on 2 dowels.
3. Fit flywheel bolts.
4. Using assistance, restrain flywheel and tighten
flywheel bolts to 78 Nm (58 lbf.ft).
DRIVE PLATE AND RING GEAR ASSEMBLY
Drive plate and ring gear assembly - remove
1. Suitably identify each component to its fitted
position.
2. Remove 4 bolts securing drive plate assembly.
3. Remove clamp ring and drive plate assembly.
NOTE: Dowel located.
4. Remove 6 Allen bolts securing hub aligner to
crankshaft, remove hub aligner.
5. Remove and retain selective shim - if fitted.
